Dick Locke's older Neal Site Saturn and Jupiter Pictures
Copyright ©  by Dick Locke.  All Rights Reserved.  Contact and Image Use Information

My "main" planets page is here


Still More Saturn here




Saturn

Using the Celestron "NexImage" and Takahashi Toa 130 telescope, 2x barlow, 22 seconds of video processed in Registax.

4/26/03 NHAC Neal Site




This image is a "stack" of 29 individual images (each about 1/4 sec. exposure time) of Saturn, combined and averaged together.  I did some sharpening and minimal color correction in Photoshop.  Despite the fact that Saturn was fairly low in the sky, conditions & seeing were very good.  You can see the planet's shadow against the rings quite clearly.   Can you identify where the Sun is, relative to the planet?

-- Taken through my telescope with my Olympus C4040 digital camera & a Teleview 5x Barlow
-- I did the stacking & averaging in a program called ImagesPlus




Jupiter. You can see the moon IO's shadow on the right. If you look closely, you can see the moon itself about 1/2 the planet to the left.  Same details as above.

A couple of other items below...

Above are M81 and M82 in Ursa Major.  These are galaxies, with M82 being on the upper left looking like a small cigar.  M81 is the rounder galaxy in the lower middle.  I had hoped to take several images of this to stack, but that didn't work out.  This is a single, 16 second exposure with my Olympus C4040 (16 seconds is the max. exposure of the camera) coupled to my telescope (Tak FS 102) via a 40mm EP (no barlows).  As of 2006 I have a much better shot of these here. M81 and M82



Above is the beehive cluster, M44, in Cancer.  This was an experiment to see what I could do with the digital camera.  It's not too bad, but I think this one would show better color with film.  Same data as previous.

My "main" planets page

Go to my astrophotography page
